Tech Specs
Device Type
LED-backlit LCD monitor - 22"
Panel Type
TN
Aspect Ratio
16:9
Native Resolution
Full HD (1080p) 1920 x 1080 at 60 Hz
Pixel Pitch
0.248 mm
Brightness
250 cd/m²
Contrast Ratio
1000:1
Response Time
5 ms (black-to-white)
Colour Support
16.7 million colours
Input Connectors
VGA, DisplayPort
Display Position Adjustments
Tilt
Screen Coating
Anti-glare, 3H Hard Coating
Colour
Black
Dimensions (WxDxH) - with stand
51.22 cm x 18 cm x 39.67 cm
Weight
3.36 kg
Localisation
Thailand, Malaysia, Singapore, India
Environmental Standards
ENERGY STAR Qualified
Compliant Standards
Plug and Play, DDC/CI, RoHS, CECP, TCO Displays, EDID compatible
Manufacturer Warranty
3-year warranty
General
Display Type
LED-backlit LCD monitor / TFT active matrix
Diagonal Size
22"
Viewable Size
21.5"
Panel Type
TN
Aspect Ratio
16:9
Native Resolution
Full HD (1080p) 1920 x 1080 at 60 Hz
Pixel Pitch
0.248 mm
Brightness
250 cd/m²
Contrast Ratio
1000:1
Colour Support
16.7 million colours
Response Time
5 ms (black-to-white)
Vertical Refresh Rate
56 - 76 Hz
Horizontal Refresh Rate
30 - 83 kHz
Horizontal Viewing Angle
170
Vertical Viewing Angle
160
Screen Coating
Anti-glare, 3H Hard Coating
Backlight Technology
WLED
OSD Languages
Chinese (simplified), Brazilian Portuguese, English, German, French, Russian, Spanish, Japanese
Features
72% (CIE 1931) colour gamut, 84% (CIE 1976) colour gamut, LED edgelight system, PowerNap, Dell Custom Color, Flicker Free technology, BFR/PVC-free, Energy Gauge, Mercury free, backlight dimming control
Colour
Black
Dimensions (WxDxH)
51.22 cm x 18 cm x 39.67 cm - with stand
Weight
3.36 kg
Connectivity
Interfaces
- VGA
- DisplayPort
Mechanical
Display Position Adjustments
Tilt
Tilt Angle
-5/+21
VESA Mounting Interface
100 x 100 mm
Miscellaneous
Features
Security lock slot (cable lock sold separately), LED indicator, integrated cable management, VESA interface support, Dell Soundbar mounting slots, arsenic free
Included Accessories
VESA screw cover
Cables Included
1 x DisplayPort cable - DisplayPort to DisplayPort
Mounting Kit
Optional
Compliant Standards
Plug and Play, DDC/CI, RoHS, CECP, TCO Displays, EDID compatible
Localisation
Thailand, Malaysia, Singapore, India
Security Slot Type
Kensington security slot
Power
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
18 Watt
Power Consumption Stand by
0.3 Watt
Power Consumption Sleep
0.3 Watt
Power Consumption (Off Mode)
0.3 Watt
Software / System Requirements
Included Software
Drivers & Utilities, Dell Display Manager
Dimensions & Weight
Dimensions & Weight Details
- With stand - width: 51.22 cm - depth: 18 cm - height: 39.67 cm - weight: 3.36 kg
- Without stand - width: 51.22 cm - depth: 5.05 cm - height: 30.37 cm - weight: 2.84 kg
Environmental
Standards
ENERGY STAR Certified
Yes
Manufacturer
Warranty
Service & Support
Limited warranty - 3 years
Environmental
Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 80% (non-condensing)
Compatibility
This
product is compatible with the following systems:
- OptiPlex 5055 SFF
- OptiPlex 7050 MT
- OptiPlex 5050 MFF
- Precision Workstation T3420
- OptiPlex 3040 Micro
- OptiPlex 3050 MT
- OptiPlex 5050 MT
- OptiPlex 7050 MFF
- OptiPlex 5050 SFF
- OptiPlex 3050 SFF
- OptiPlex 3050 MFF
- OptiPlex 5055 MT
- OptiPlex XE2 SFF
- OptiPlex 7050 SFF
- OptiPlex 7040 MT
